Model

GT15Q-HR

GT15Q-HU

Scanner

Readable codes

2D Code

QR code, MicroQR code, PDF417, MicroPDF417,Maxi code, DataMatrix(ECC200), GS1 DataBar Composite

Bar Code

EAN-13/8(JAN-13/8), UPC/EAN(with add-on), Interleaved 2 of 5, CODABAR(NW-7), CODE 39, CODE 93, CODE128, GS1-128, GS1 DataBar

Resolution

2D Code

0.167mm

Bar Code

0.125mm

Marker

Area guide maker

PCS Value

Not less than 0.45

Skew Angle

360°

Angle

±35°

Reading confirmation

3-color LED (red, blue and green) buzzer (with volume control), vibrator

Communications

Communication system

RS-232C

USB1.1compliant

Interface

Connector I/F

Dsub-9S

USB Type A(2)(3)

Power

Power supply

original AC adapter

Supplied from the connection target

Environment Requirements

Drip-proof

IP54

Shock Resistance(1)

Dropped from 2m above concrete floor, on all 6 faces,5 times each(total 30 times)

Temperature

0 to 50°C

Humidity

10 to 90%RH(without dews)

Illumination

20-10,000lx(Fluorescent lamp in daytime)

Weight(ex.cable)

Approx. 210g
