Opticon OPI3601二维成像条码阅读器
opi3601基于条码扫描仪的二维成像。专门设计的是一个最小和最轻的手持扫描仪可在今天的市场。该opi3601已经看到了相当大的成功关键市场的医疗保健领域内的腕带扫描和零售扫描数据矩阵码对零售业产生和手机条码的电子客票和优惠券赎回。
opi3601手枪式二维CMOS成像条码扫描器提供一个完整的套件，包括手自由站允许用户选择双手自由扫描或扫描的手。新的高质量的扫描引擎能够阅读甚至最难读的条形码，无论是印刷或条码，手机屏幕。我们已经开发了具有增强运动能力允许更快的扫描操作和明亮的LED瞄准功能，操作简单、快捷的opi3601。恭维其先进的性能，opi3601能够承受1.5米混凝土下降。
为opi-3601典型应用：
零售扫描数据矩阵码的GS1在POS 电子优惠券赎回的手机 保健应用手腕带扫描病人的管理
规格：
Operating indicators |
|
Visual |
1 LED (red/green/orange) |
Non-visual |
Buzzer |
Operating keys |
|
Entry options |
1 scan key |
Communication |
|
RS232 |
DB9 PTF connector with external power supply |
Keyboard Wedge |
MiniDIN6 F/M connector |
USB |
Ver. 2.0, HID/VCP, USB-A connector |
Power |
|
Voltage requirement |
6V ± 5% (Keyboard Wedge), 6V (min. 4.5, max. 6.5V) (RS232) |
Current consumption |
Max. 350mA (max typical use), 75mA (standby) |
2D Imager Optics |
|
2D Light source |
Green aiming LED, illumination LEDs |
2D Scan method |
CMOS area sensor, 752 x 480 pixels, gray scale |
2D Scan rate |
60 fps |
2D Trigger mode |
Manual, multiple read, auto-trigger, stand detection |
2D Image format |
Windows Bitmap, JPEG, TIFF |
2D Gradulation |
1024, 256, 16, 2 |
2D Image output mode |
4 resolutions (full, 1/2, 1/3, 1/4), 2 ranges (horizontal, vertical) |
2D Reading pitch angle |
-50 to 0°, 0 to +50° |
2D Reading skew angle |
-50 to 0°, 0 to +50° |
2D Reading tilt angle |
360° |
2D Focal plane |
104 mm |
2D Curvature |
R>16 mm (12-digit 0.15 mm Codabar), R>20 mm (13-digit UPC) |
2D Min. Resolution at PCS 0.9 |
QR code: 0.127 mm / 5 mil, DataMatrix: 0.169 mm / 7 mil |
2D Min. PCS value |
0.3 |
2D Field of view |
Horizontal 40.6o, Vertical 26.4o |
2D Depth of field |
at Code 39: 65 - 105 mm / 2.56 - 4.13 in (0.127 mm / 5 mil), 45 - 185 mm / 1.77 - 7.28 in (0.254 mm / 10 mil) 50 - 250 / ,1.97 - 9.87 in (0.508/20 mil) at QR Code: 70 - 95 mm / 2.76 - 3.74 in (0.212 mm / 8.4 mil), 35 - 165 / 1.38 - 6.50 in (0.381 / 15 mil) |
Supported Symbologies |
|
Barcode (1D) |
JAN/UPC/EAN incl. add on, Codabar/ NW-7, Code 11, Code 39, Code 93, Code 128, GS1-128 (EAN-128), GS1 DataBar (RSS), IATA, Industrial 2of5, Interleaved 2of5, ISBN-ISSN-ISMN, Matrix 2of5, MSI/ Plessey, S-Code, Telepen, Tri-Optic, UK/Plessey |
Postal code |
Chinese Post, Intelligent Mail Barcode, Korean Postal Authority code, POSTNET |
2D code |
Aztec Code, Aztec Runes, Chinese Sensible code, Codablock F, Composite codes, Data Matrix (ECC200/EC0-140), Maxi Code (mode 2~5), MicroPDF417, Micro QR Code, PDF417, QR code |
Durability |
|
Temperature in operation |
-20 to 50 °C / -4 to 122 °F |
Temperature in storage |
-20 to 60 °C / -4 to 140 °F |
Humidity in operation |
5 - 90% (non-condensing) |
Humidity in storage |
5 - 90% (non-condensing) |
Ambient light immunity |
Fluorescent 10,000 lx max, Direct sun 100,000 lx max, Incandescent 10,000 lx max |
Drop test |
1.5 m / 5 ft drop onto concrete surface |
Vibration test |
10 - 100 Hz with 2G for 1 hour |
Protection rate |
IP 42 |
Physical |
|
Dimensions (w x h x d) |
56 x 148.6 x 108.1 mm / 2.20 x 5.85 x 4.26 in |
Weight body |
Ca. 85 g / 3 oz (excl. cable) |
Case |
ABS, Black or White |
Regulatory & Safety |
|
Product compliance |
CE, FCC, VCCI, RoHS, IEC 62471-1, IEC 60825-1 Class 1, IEC 60950-1 |
保健应用：药房管理电子病历登记校内护理效率记录跟踪
零售应用：项目鉴定价格检查手机优惠券忠诚卡识别仓库管理移动
票务应用：入口控制检查铅跟踪访问者的数据存储
附件：
所附的项目
opi3601电源电源标准封闭的RS232和键盘楔版本…
更opi3601站该opi3601供应作为一个完整的套件，包括手自由站允许
