Honeywell Thor VM1车载数据终端

Thor VM1 车载移动终端
霍尼韦尔Thor VM1车载移动终端-叉车移动终端的理想选择，以创新的设计超越所有竞争者。在如今的供应链中，唯一不变的就是变化。干扰，无论是短期的如一个叉车故障，或长期的如自然灾害，都是不可逃脱的工作的一部分。供应链只有采用能够带给他们最大灵活性的移动数据处理技术，才能够很好的应对这些干扰。Thor VM1车载移动终端（VMC）-霍尼韦尔开发的第十代VMC产品，将会提供前所未有的灵活性。

特征及优点：
Thor VM1 车载移动终端 Features and Benefits
智能底座：像使用笔记本电脑扩展坞底座一样只要几秒钟就能实现主机安装和拆卸，且具有高工业等级的耐用性和密封性；随着工作量的变化，动态转换使用者和数据终端，可大大提升工作效率，同时支持数据终端从一辆车快速转移安装到另一辆上，只用标准时间的1/6，大大降低了维护成本

现场可更换前面板：将最易磨损和被破坏的两个部件--键盘和触摸屏，设计为用户可更换的模块化配件，减少了投资和维护成本；以备用面板配件取代备用数据终端，使用者的系统投资进一步降低

点火控制：消除了车辆电池用尽造成的维修花费和效率的降低；在叉车熄火后，设备可以配置为自动进入待机或休眠状态，节省操作时间，同时消除了仓库管理的顾虑

附件：
Thor VM1 车载移动终端 Accessories
To view and download the Thor VM1 & VM2 accessory catalog click here

VM1052CABLE - USB Y Cable - D9 Male to USB type A plug 6 ft. (host) and USB type A socket 0.5 ft (client). Thor VM1 & VM2 USB port to USB connector for host and USB connector for client
VM1060CABLE - Headset adapter cable, D15 to 4 pin quick disconnect connector. A headset is still required. This cable is required whenever a headset is used with a Thor VM1 & VM2. A four pin quick disconnect extension cord and an LXE headset with the four pin quick disconnect connector are also required. Audio and CANbus share one connector on the Thor VM1 & VM2 dock. This connector can be used for either audio or for CANbus but not both on the same vehicle.
VM1079CABLE - CANbus Y cable - D15 to 9 pin F SAE J1939 (Deutsch) and 9 Pin M SAE J1939 (Deutsch), 6 ft (1.8m). Audio and CANbus share one connector on the Thor VM1 & VM2 dock. This connector can be used for either audio or for CANbus but not both on the same vehicle.

Power Cables & Supplies
VX89303PWRSPLY - Power Supply, DC/DC 50-150V trucks, 60W, this power supply is required for installations requiring more than Thor VM1 & VM2 maximum rating of 60 VDC.
VM1301PWRSPLY - AC/DC power supply, FCC Approvals, US cord included. Not for use in Hazardous Locations. Requires Power VM1078CABLE Adapter Cable

VM1302PWRSPLY - AC/DC power supply, (C14 type power cord required), not for use in Hazardous Locations. Requires Power VM1078CABLE

Adapter Cable
VM1078CABLE - Power Cable Adapter for AC power supply, required when using the VM1301PWRSPLY or VM1302PWRSPLY AC/DC power supplies
VM1054CABLE - DC Power Cable (spare), one of these cables is included with each Thor VM1 & VM2 dock
VM1077CABLE - Adapter cable for VX6/VX7 DC power cable, adapts VX6/VX7 power cable to Thor VM1 & VM2 power connector.
9000090CABLE - AC Power Cable, C14 type, Schuko (EUROPEAN) AC AC Power Cable, C14 type, Schuko (EUROPEAN) Power Cable, C14 type, Schuko, AC Power Cable, C14 type, Schuko (EUROPEAN)
9000091CABLE - AC Power Cable, C14 type, Denmark 3-pin
9000092CABLE - AC Power Cable, C14 type, Italy 3-pin
9000093CABLE - AC Power Cable, C14 type, Switzerland 3-pin
9000094CABLE - AC Power Cable, C14 type, British 3-Blade
9000097CABLE - AC Power Cable, C14 type, Australia

VM1376BATTERY - Replacement UPS battery
VX89351PWRSPLY - Screen Blanking Switch Box Universal, the screen blanking switch box enables the screen on the Thor VM1 & VM2 to be automatically blanked when the vehicle is moving.
VX89352PWRSPLY - Screen Blanking Switch Box China Only, the screen blanking switch box enables the screen on the Thor VM1 & VM2 to be automatically blanked when the vehicle is moving.

Antenna Parts & Accessories
VM1277ANTENNA - Remote 802.11 WLAN Dual band Antenna Kit, 14 ft (4M), Kit includes Antenna, Cable and Bracket
VM1278ANTENNA - Mobile WWAN 7-band Antenna Kit, 14 ft (4M), magnetic mount
VM1279ANTENNA - Mobile WWAN 7-band Antenna Kit, 14 ft (4M), adhesive mount, Kit includes Antenna and Cable. Bracket not needed
VM1288ANTENNA - GPS Antenna Kit, 14 ft (4M), adhesive mount, Kit includes Antenna and Cable. Bracket not needed

Mounting Kits
VM1001BRKTKIT - RAM mount kit, round base, short arm 5”(128mm), ball for vehicle dock rear, Kit includes hardware for mounting to the Thor VM1 & VM2 Smart Dock, VM1001VMCRADLE, Kit includes a round base with a D (2.25”/57mm) RAM ball for the vehicle side mounting. Hardware for mounting the base to the vehicle is not included. This mount typically requires drilling holes in the vehicle.
VM1002BRKTKIT - RAM mount kit, round base, medium arm, 8.5” (215mm), ball for vehicle dock rear, Kit includes hardware for mounting to the Thor VM1 & VM2 Smart Dock, VM1001VMCRADLE, Kit includes a round base with a D (2.25”/57mm) RAM ball for the vehicle side mounting. Hardware for mounting the base to the vehicle is not included. This mount typically requires drilling holes in the vehicle.
VM1003BRKTKIT - RAM mount kit, round base, long arm, 13”(330mm), ball for vehicle dock rear, Kit includes hardware for mounting to the Thor VM1 & VM2 Smart Dock, VM1001VMCRADLE, Kit includes a round base with a D (2.25”/57mm) RAM ball for the vehicle side mounting. Hardware for mounting the base to the vehicle is not included. This mount typically requires drilling holes in the vehicle.
VM1004BRKTKIT - RAM mount kit, flat clamp base, short arm 5” (128mm) ball for vehicle dock rear, Kit includes hardware for mounting to the Thor VM1 & VM2 Smart Dock, VM1001VMCRADLE, Kit includes a flat clamp type RAM ball for the vehicle side mounting. These clamp balls attach directly to the roof support arm of most fork lift vehicles without the need for additional mounting hardware.
VM1005BRKTKIT - RAM mount kit, flat clamp base, medium arm 215mm (8.5”), D ball for dock rear, Kit includes hardware for mounting to the Thor VM1 & VM2 Smart Dock, VM1001VMCRADLE, Kit includes a flat clamp type RAM ball for the vehicle side mounting. These clamp balls attach directly to the roof support arm of most fork lift vehicles without the need for additional mounting hardware.
VM1006BRKTKIT - RAM mount kit, flat clamp base, long arm 330mm (13”), D ball for dock rear, Kit includes hardware for mounting to the Thor VM1 & VM2 Smart Dock, VM1001VMCRADLE, Kit includes a flat clamp type RAM ball for the vehicle side mounting. These clamp balls attach directly to the roof support arm of most fork lift vehicles without the need for additional mounting hardware.
VM1007BRKTKIT - RAM mount kit, plate base, short arm, 5” (128mm), ball for vehicle dock rear, Kit includes hardware for mounting to the Thor VM1 & VM2 Smart Dock, VM1001VMCRADLE, Kit includes a metal plate with a D size RAM ball attached. Plate mounting hardware is not included.
VM1008BRKTKIT - RAM mount kit, plate base, medium arm 8.5” (215mm), ball for vehicle dock rear, Kit includes hardware for mounting to the Thor VM1 & VM2 Smart Dock, VM1001VMCRADLE, Kit includes a metal plate with a D size RAM ball attached. Plate mounting hardware is not included.
VM1009BRKTKIT - RAM mount kit, plate base, long arm 13” (330mm), ball for vechile dock rear, Kit includes hardware for mounting to the Thor VM1 & VM2 Smart Dock, VM1001VMCRADLE, Kit includes a metal plate with a D size RAM ball attached. Plate mounting hardware is not included.
VM1011BRACKET - Thor VM1 & VM2 Adapter Bracket for VX6/7 U-Bracket Mount, adapts a Thor VM1 & VM2 to fit a VX1, VX2, VX4, VX5, VX6 or VX7 U-Bracket Mount

VM1010BRKTKIT - Thor VM1 & VM2 U-Bracket mount kit, includes U-Bracket, Adapter bracket and all required hardware

Mounting Ball Parts
VM1001RAMBALL - Thor VM1 & VM2 dock ball, D-SIZE, with mounting hardware. Recommended for spare docks. These parts are included in all Thor VM1 & VM2 mounting kits.
VX89A030RAMBALL - BALL D-SIZE 2.25, ROUND 3.68 BASE
VX89A031RAMBALL - BALL D-SIZE 2.25, FLAT 2.5 CLAMP BASE
VX89A032RAMBALL - BALL D-SIZE 2.25, 4.75 SQUARE BASE
VX89A033RAMBALL - BALL D-SIZE 2.25, CLAMP BASE FOR 1.25 TO 1.875 PIPE MOUNT
VX89A040RAMBALL - BALL D-SIZE 2.25, CLAMP BASE FOR 2 TO 2.5 PIPE MOUNT

Mounting Arm Parts
VX89A502RAMARM - RAM SHORT ARM, 128mm (5”) for D-SIZE 2.25 balls.
VX89A501RAMARM - RAM MEDIUM ARM, 215mm (8.5”) for D-SIZE 2.25 balls.
VX89A503RAMARM - RAM LONG ARM, 330mm (13”) for D-SIZE 2.25 balls.

Mounting Plate Parts
VX89531PLATE - RAM METAL TABLE STAND
VX89535PLATE - PLATE, TRUCK SIDE FOR 1 D-SIZE 2.25 BALL, NO BALL INCLUDED
9000033PLATE - Backup plate - Set of 2, Hardware included. These two plates can be mounted on each side of the fork lift roof. Various Ram balls can be attached to these plates to avoid having to drill mounting holes or weld the fork lift.

Miscellaneous
VM1512LCDFILM - Removable touch screen protective film with anti-glare coating, 10 pack
VM1510STYLUS - Stylus Kit with tethers, 5 pack, Replacement Front Panels
VM1530FRONTPNL - Front Panel: ANSI keyboard with standard touch screen
VM1531FRONTPNL - Front Panel: 3270 keyboard with standard touch screen
VM1532FRONTPNL - Front Panel: 5250 keyboard with standard touch screen
VM1533FRONTPNL - Front Panel: 12 key keyboard with standard touch screen
VM1534FRONTPNL - Front Panel: ANSI keyboard with cold storage touch screen
VM1535FRONTPNL - Front Panel: 3270 keyboard with cold storage touch screen
VM1536FRONTPNL - Front Panel: 5250 keyboard with cold storage touch screen
